Liberta Cor-Ten 700

Create a harmonious, rusty layout with Liberta™ Cor-Ten 700 for ventilated Cor-Ten facade systems.



Ruukki® Emotion
Available also with perforation and backlighting.

The information on our website is accurate to the best of our knowledge and understanding. Although every effort has been made to ensure accuracy, the company cannot accept any responsibility for any direct or indirect damages resulting from possible errors or incorrect application of the information of this publication. We reserve the right to make changes.

Properties

700.ashx

Model name
Liberta Cor-Ten 700
Depth
30 mm
Horizontal joint
10 mm
Vertical joint
20, 25, 30 mm
Fastening Style
Standard fix


Perforation layout

perforation

Dimension/holemm
a≥10
b≥10
cd+15, d+25, d+30
d12, 16, 20, 30


Symmetrical perforation: Fully perforated in symmetrical square layout. Only 1 hole size (d) and distance (a, b, c) per product.

Art perforation: Fully or partly perforated in freely chosen locations. All hole sizes (d) and distances (c) available per product.


Material steel Cor-Ten 1.50 mm, panel sizes

Liberta 700_size table

Materials

Material Material thickness (mm) Weight (kg/m2) Surface treatment Reaction to fire
Steel Cor-Ten A * 1.5 14.5 - A1

Due to its unique chemical composition, Cor-Ten weather-resistant structural steel sheet has a significantly better ability to resist atmospheric corrosion than similar general structural steels. Weather-resistant steel is used in architectural applications without requiring any separate surface treatment. Use of weather-resistant steel thus eliminates the need for surface treatments during the manufacturing and operational periods, in turn lowering the environmental load and costs throughout the product’s life cycle.

The weather resistance of the product is due to its oxide layer i.e. the patina which forms on the steel surface which is resistant to the action of alloys and has low oxygen permeability. The oxide layer is created when weather-resistant steel is wetted and dried repeatedly. The protective surface layer forms in normal weather conditions within 18…36 months. The patina layer is initially reddish brown in colour, becoming darker in tone over the course of time. In industrial environments the patina forms more rapidly on the steel and darkens more than in cleaner rural environments. The protective patina layer cannot form, however, if the surface of the steel is continuously damp or dirty.

Cor-Ten A grade steel is used for the manufacture of panels (S355J0WP-COR-TEN A).

BIM objects

To make both architectural and structural design work easier, with accurate product information in 3D form, we offer a selection of CAD / BIM -objects for Autodesk Revit and ArchiCAD.

Download documents

Declaration of performance

Order form

Maintenance instructions

Technical documents

Fill the form below and we'll provide you a link to document library from where you will get the most important documents e.g.

  • detail drawings
  • dimensional drawings
  • instructions and manuals
