Sandwich panel SPA EE Patina



Sandwich panel SPA EE Patina is available in thickness 200+ and 230.

With precise and Ruukki specific manufacturing tolerances, and factory-fitted seals on the panel joints, the Ruukki® Energy panel structure with its seams forms a very airtight solution. Together with Ruukki Airtightness package it’s possible to achieve excellent airtightness to the entire building. This can decrease energy costs and CO2 emissions up to 30%. Read more on airtightness package

Using Ruukki's solutions you can receive more credits in LEED and BREEAM certification systems.

With the filling consisting of non-combustible, lightweight and environmentally friendly mineral wool, this sandwich panel meets the insulation regulations in Scandinavia.

Ruukki® Patina panel is made of natural and untreated Cor-Ten® steel. The unique joint structure of the panel prevents corrosion at the joints (patent pending). The new, innovative panel is also maintenance free since it repairs scratches over time itself.

Application:

  • External walls (standard fix)

The method for joining Cor-Ten® steel-based sandwich panels, preventing corrosion formation in the joint, is patented.





The information on our website is accurate to the best of our knowledge and understanding. Although every effort has been made to ensure accuracy, the company cannot accept any responsibility for any direct or indirect damages resulting from possible errors or incorrect application of the information of this publication. We reserve the right to make changes.

Properties

Model name
Sandwich panel SPA EE Patina
Standard module width
1200 mm
Minimum length
2000 mm
Maximum Length
13499 mm
External facing thickness
0.7 mm
Internal facing thickness
0.5 mm
Air Tightness
q50=0,01 m3/hm2 (pressure and suction)
Thickness D (mm) 200+ 230
Weight (kg/m2) 25.4 27.6
U-value (W/m2K) 0.18 0.16
Sound insulation Rw (dB) 28 28
Reaction to fire A2-s1. d0 A2-s1. d0
GWP-total, A1-A3 (kg CO₂ₑ/m²) 31,9 33,8
GWP-total, A1-A3 (kg CO₂e/m²) for Ruukki® LowCarbon - -

Coatings and colors

Materials

FacingCoatingCorrosivity categoryUV resistance Colours
ExternalCor-Ten®C3--
InternalPolyesterC3RR20
InternalFoodsafe laminate *C4White

*) optional material

UV resistance describes how well the coating is able to keep its original colour and gloss levels in accordance with EN10169. The higher the class, the better the resistance.

Corrosivity categories describe the outdoor climate conditions in accordance with EN12944. The higher the category, the more corrosive environment.



Surface variations








FacingProfile options
ExternalFlat F
InternalFlat F, Micro 15, Linear 50, Rib 150, Rib 200, Rib 600
