Sandwich panel nSPB WE Patina

Sandwich panel nSPB WE Patina is available in thicknesses 150 - 230 mm.

With precise and Ruukki specific manufacturing tolerances, and factory-fitted seals on the panel joints, the Ruukki® Energy panel structure with its seams forms a very airtight solution. Together with Ruukki Airtightness package it’s possible to achieve excellent airtightness to the entire building. This can decrease energy costs and CO2 emissions up to 30%. Read more on airtightness package. Using Ruukki's solutions you can receive more credits in LEED and BREEAM certification systems.

It is a perfect solution for most buildings and structures, combining high quality with very good technical properties.

The filling consisting of non-combustible and environmentally friendly soft mineral wool with low thermal conductivity coefficient ensures very good thermal insulation of this panel. Properly milled core increases air-tightness and provides high sound insulation.

Ruukki® Patina panel is made of natural and untreated Cor-Ten® steel. The unique joint structure of the panel prevents corrosion at the joints (patent pending). The new, innovative panel is also maintenance free since it repairs scratches over time itself.

Application:

  • External walls (standard fix)

The method for joining Cor-Ten® steel-based sandwich panels, preventing corrosion formation in the joint, is patented.

The information on our website is accurate to the best of our knowledge and understanding. Although every effort has been made to ensure accuracy, the company cannot accept any responsibility for any direct or indirect damages resulting from possible errors or incorrect application of the information of this publication. We reserve the right to make changes.

Properties

Model name
Sandwich panel nSPB WE Patina
Standard module width
1100 mm
Minimum length
2000 mm
Maximum Length
12000 mm
External facing thickness
0.7 mm
Internal facing thickness
0.5 mm
External Fire Exposure
NRO
Air Tightness
q50=0,01 m3/hm2 (pressure and suction)
Thickness D (mm) 150 180 200 230
Weight (kg/m2) 24.9 27.4 29.2 31.7
U-value (W/m2K) 0.26 0.22 0.19 0.17
Sound insulation Rw (dB) 29 30 30 30
Reaction to fire A2-s1, d0 A2-s1, d0 A2-s1, d0 A2-s1, d0
GWP-total, A1-A3 (kg CO₂ₑ/m²) 31,7 32,8 33,5 34,6
GWP-total, A1-A3 (kg CO₂e/m²) for Ruukki® LowCarbon - - - -
Wall fire resistance values & max span horizontal / vertical orientation (m): 150 180 200 230
EI 30 7,5/- 7,5/- 7,5/- 7,5/-
EI 60 7,5/- 7,5/- 7,5/- 7,5/-
EI 90 6,0/- 6,0/- 6,0/- 6,0/-

Coatings and colors

Materials

FacingCoatingCorrosion classUV resistance Colours
ExternalCor-Ten®C3--
InternalPolyesterC3RAL9002, RAL9010

UV resistance describes how well the coating is able to keep its original colour and gloss levels in accordance with EN10169. The higher the class, the better the resistance.

Corrosivity categories describe the outdoor climate conditions in accordance with EN12944. The higher the category, the more corrosive environment.



Surface variations







FacingProfile options
ExternalFlat F
InternalFlat F, Linear L, Linear 25
