Invisible outer corner flashing EA1ECI2

Invisible outer corner flashing EA1ECI2 for listing the vertical seam between panels (SPA 300) in the outer corner without visible fixing screws. Suitable for SPA panels with a thickness of 300 mm. Flush mounting washers are used to fasten the panels according to Invisible flashing details and instructions.

The Invisible EA1EXB6 vertical corner flashing is required to attach this list.

1 / 2

2 / 2

Save this product information as PDF

Send contact request

The information on our website is accurate to the best of our knowledge and understanding. Although every effort has been made to ensure accuracy, the company cannot accept any responsibility for any direct or indirect damages resulting from possible errors or incorrect application of the information of this publication. We reserve the right to make changes.

Properties

Product name	Invisible outer corner flashing EA1ECI2
Length	1245 mm
Material thickness	0,6 mm
Weight	4.99 kg/pcs

Note:

For unobtrusive listing of the vertical seam between the SPA panels (230 mm) in the outer corners of the building
At the top of the list there are three mounting holes / side, of which to only one becomes a screw (1 screw / side).
Recommended screw type: List screw S1E42013GE 1000.
All list screws are hidden after installation.
The Invisible EA1EXB4 vertical base flashing is required to attach this list.
The length of the list includes an overlap of 40 mm.
