Invisible outer corner flashing EA1ECI

Invisible outer corner flashing EA1ECI for listing the vertical seam between the SPA panels in the outer corner without visible fixing screws. Flush mounting washers are used to fasten the panels according to Invisible list details and instructions.

The Invisible EA1EXB4 vertical corner flashing is required to attach this list. In this case, flush mounting washers are used to fasten the panels in accordance with Invisible list details and instructions.

1 / 2

2 / 2

Save this product information as PDF

Send contact request

The information on our website is accurate to the best of our knowledge and understanding. Although every effort has been made to ensure accuracy, the company cannot accept any responsibility for any direct or indirect damages resulting from possible errors or incorrect application of the information of this publication. We reserve the right to make changes.

Properties

Product name	Invisible outer corner flashing EA1ECI
Length	1245 mm
Material thickness	0,6 mm
Weight	4.1 kg/pcs

Note:

For unobtrusively listing of the vertical seam between the SPA panels (150-200 mm) in the outer corners of the building
At the top of the list there are three mounting holes / side, of which to only one becomes a screw (1 screw / side).
Recommended screw type: List screw S1E42013GE 1000.
All list screws are hidden after installation.
The Invisible EA1EXB4 vertical base flashing is required to attach this list.
The length of the list includes an overlap of 40 mm.
