Cladding Lamella Straight 100

Create a straightforward appearance with Lamella straight 100 for ventilated steel and aluminium facade systems.



Ruukki® Emotion
Available also with perforation and backlighting.

The information on our website is accurate to the best of our knowledge and understanding. Although every effort has been made to ensure accuracy, the company cannot accept any responsibility for any direct or indirect damages resulting from possible errors or incorrect application of the information of this publication. We reserve the right to make changes.

Properties

Groove 100.ashx

Model name
Cladding Lamella Straight 100
Effective height
Standard 300 (300...350) mm
Width
150...3000 mm
Depth
30 mm


Perforation layout

perforation

Dimension/holemm
a≥10
b≥10
cd+15, d+25, d+30
d12, 16, 20, 30


Symmetrical perforation: Fully perforated in symmetrical square layout. Only 1 hole size (d) and distance (a, b, c) per product.

Art perforation: Fully or partly perforated in freely chosen locations. All hole sizes (d) and distances (c) available per product.


Materials

Material Material thickness (mm) Weight (kg/m2) Surface treatment Reaction to fire
Steel 1.2 12.8 GreenCoat Hiarc * A1
Steel 1.2 12.8 Powder coating A2 - s1,d0
Aluminium 1.5 5.61 Powder coating **  -
Aluminium
1.5
5.61
PVDF * / **  -
*) Not available with perforation
**) Non-stock item





Coatings and colors

Colour chartCoatingColour
StandardGreenCoat HIARC (steel)RR20, RR21, RR23, RR40, RR41, RR42, RR43
 GreenCoat HIARC Matt (steel)RR40, RR41, RR45
ExtendedGreenCoat HIARC (steel)RR11, RR22, RR24, RR26, RR29, RR30, RR31, RR32,RR33, RR34, RR35, RR36, RR37, RR44, RR45, RR750
More RR colours
 PVDF (aluminium)Most common RAL colours

Powder paint (steel&aluminium)RAL colours

Minimum order sizes:
Standard chart: No limitations
Extended chart:
- GreenCoat HIARC (steel): 900 m2
- PVDF (aliminium): 250 m2
- Powder paint (steel&aluminium): 100 m2

Colours

BIM objects

To make both architectural and structural design work easier, with accurate product information in 3D form, we offer a selection of CAD / BIM -objects for Autodesk Revit and ArchiCAD.

Download documents

Declaration of performance

Order form

Maintenance instructions

Accessory documents

Technical documents
